Digital Identity

Digital Identity Reader Test Suite

Test the functionality of any ISO 18013-5 & ISO 18013-7 compliant reader application.

Test your mDL reader application by simulating an mDL holder application against ISO/IEC 18013-6.

Digital Identity Reader Test Suite

Validate reader applications against ISO 18013-5 & -7 for mDL, eHealth, Photo ID & mVRC mdocs.

With Digital Identity Reader Test Suite, you can test an ISO 18013-5 and ISO 18013-7 compliant reader application implementation by simulating an ISO 18013-5 and ISO 18013- 7 compliant application to test compliance to ISO 18013-5 and ISO 1 013-7, using the appropriate test specification.

The Digital Identity Reader Test Suite allows you to select your specific ISO 18013-5 and ISO 18013-7 compliant mdoc to be tested against the latest (draft) version of ISO/IEC 18013-6 and Fime’s proprietary 18013-7 test specification.

Key benefits

  • Support for European Digital Identity (EUDI) Wallet testing.

  • Easy-to-use and intuitive user interface.

  • Easy-to-read and configurable test results that can be saved and shared.

  • Test environment supports any Android 11 or later
    handset.

Key features

  • Support for a range of ISO 18013-5 and ISO 18013-7 compliant mdocs; mDL, eHealth, Photo ID & mVRC (with more to be added).

  • Connects to Android application on the handset via Android Debug Bridge (ADB) to send and receive the test data to and from the device.
  • ISO 18013-5 Interface 2 and 3 and ISO 18013-7 Annex testing.

  • Supports full ISO 18013-5 device engagement testing

    via NFC or QR code and URI for ISO18013-7.

  • Supports ISO 18013-5 digital identity transfer testing

    via NFC, BLE, Wi-Fi Aware (offline) and WebAPI over
    HTTPS v1.2 and 1.3 (online) and TCP/IP for ISO 18013-7.

How it works.

Digital Identity Reader Test Suite uses the transport layer capabilities of any Android 11 or later handset to engage with and test the transfer of ISO 18013-5 and ISO 18013-7 mdoc credentials.



What's in the box.

  • Full coverage for a range of digital identity mdocs against ISO or Fime proprietary test specifications.

  • Device engagement testing via NFC, QR code or URI.

  • ISO 18013-5 device retrieval testing via NFC, BLE, Wi-Fi Aware (offline) and server retrieval via WebAPI over HTTPS v1.2 and 1.3 (online) and TCP/IP for ISO 18013-7.

  • Connectivity for testing provided by our Android proxy application using ADB.

  • Support for ISO 18013-5 Interface 2 and 3 and ISO 18013-7 Annex A testing.

  • Easy-to-read and configurable test results that can be saved and shared mDL Interfaces.



Test Suites.

All mdocs are tested using the latest (draft) version of ISO/IEC 18013-6 and Fime’s proprietary 18013-7 test specification.

  • mDL Document Type ‘org.iso.18013.5.1.mDL’ from ISOIEC 18013-5.

  • eHealth Document Type ‘org.micov.1’ from ISO-IEC JTC 1-SC 17-WG 10_N2478 (draft).

  • Photo ID (PID) Document Type ‘org.iso.23220.photoid.1’ from ISO-IEC TS CD 23220-4 (draft).

  • Netherlands RDW mVRC (Mobile Vehicle Registration Certificate) Document Type ‘org.iso.7367.1.mvrc’ from ISO-IEC 7367 (draft).

NOTE: More ISO 18013-5 and ISO 18013-7 compliant mdocs to be added for a range of worldwide Digital Identity initiatives and wallets.


Downloads

Download our technical specifications sheets for more information.

donwload-image Fime Digital Identity Reader Test Suite flyer.pdf
